ACL VQHR & VHR Rod Bearings (Select Size)

ACL VQHR & VHR Rod Bearings

(Select Size)

Wall Sizes at crown:

Std 0: 2.500mm - 2.504mm (0.0984in - 0.0986in)
Std 1: 2.505mm - 2.509mm (0.0986in - 0.0988in)
Std 2: 2.510mm - 2.514mm (0.0988in - 0.0990in)
Std 3: 2.515mm - 2.519mm (0.0990in - 0.0992in)
Std 4: 2.520mm - 2.524mm (0.0992in - 0.0994in)

If you need help sizing your bearings message us directly

Price is per pair of bearings  (6 pairs per engine)

ACL Race Series performance engine bearings are manufactured to exacting tolerances. Micron tolerance machining supported by precision measurement systems delivers consistent accuracy to key characteristics like wall thickness and crush. This ensures reliable fit and helps maintain consistent clearances.

A blend of characteristics to provide high strength and crankshafts. excellent seizure resistance.

No flash plating is applied to further improve bearing retention and maximise heat transfer.

Improved bearing retention from higher radial contact pressure. Locks the bearing into the housing.

More effective heat dissipation through improved thermal transfer.

Definition: Gradual reduction in wall thickness between the crown and parting line.

ACL Race Series performance engine bearings feature increased eccentricity to increase improve shape adaptation to compensate for bore distortion at high speed operation.

Assists in the formation of hydrodynamic oil film.
